The  BIM-01-2-HSN2  is designed to read the engine information from the  Holley Sniper 2 EFI (Sniper 2 only). The BIM-01-2-HSN2 module is a direct plug in using the supplied  harness for a simple connection to the Holley Sniper 2 EFI system.

The  BIM-01-2-HSN2   will collect and output the following information to Dakota Digital Instrument Systems *:

Always available:

• Tachometer
• Engine Coolant Temp
• Intake/ Manifold Temp.
• Air/ Fuel Ratio
• MAP

Dakota Digital cannot guarantee the presence or accuracy of the available readings as this is a function of the ECM and matching functional sensors.

*Compatible Dakota Digital instrument system:  VHX,  HDX,  GRFX,   RTX  and  VFD3  systems with a black plastic control module. For any BIM-compatible control boxes which contain the 3.5mm headphone jack BIM input, add part number  394193  adaptor harness.   Earlier instrument systems with an aluminum control module are not capable of BIM connectivity.

* For the original Sniper EFI please order the BIM-01-2-HLLY.
